Auto Labeling Machine

Direction : Left to Right
Production Speed : 80 to 100 bottle /min (depends on container and label size)
Label Accuracy : ±1% (for wrap around label ±1.5 mm)
Servo Motor and Driver: 750 Watt (1Nos) [ Make : Delta/Panasonic/Fuji ]
A.C. Drive : 1 HP, 240V Single Phase
HMI & PLC : 4.3” (1 No) [ Make : Delta/Panasonic/Fuji ]
Sensor : Gap sensor, Product sensor
Power Characteristics : 230 Volts AC 50Hz
Overall Dimension in mm : 1840 (l) X 1300(w) X 1350 (h)
Conveyor Height : 800mm + 50mm
Input Specification : (A) Round container dia. : 25 to 80mm
Label Roll Diameter : (B) Label : 30 to 180mm (LT 16 to 100mm (W))
